PT2L7RC4
  • Share:

TE Connectivity Potter & Brumfield Relays PT2L7RC4

Manufacturer No:
PT2L7RC4
Manufacturer:
TE Connectivity Potter & Brumfield Relays
Package:
Bulk
Datasheet:
PT2L7RC4 Datasheet
ECAD Model:
-
Description:
RELAY GEN PURPOSE DPDT 12A 24V
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Mounting Type:DIN Rail
Coil Voltage:24VAC
Contact Form:DPDT (2 Form C)
Contact Rating (Current):12 A
Switching Voltage:400VAC - Max
Coil Current:-
Coil Type:Non Latching
Features:Lighted Indicator, Mechanical Indicator, Socket Included, Test Button
Termination Style:Screw Terminal
Seal Rating:-
Coil Insulation:-
Must Operate Voltage:19.2 VAC
Must Release Voltage:7.2 VAC
Operate Time:-
Release Time:-
Operating Temperature:-40°C ~ 70°C
Contact Material:Silver Nickel (AgNi)
Relay Type:General Purpose
0 Remaining View Similar

In Stock

$24.79
21

Please send RFQ , we will respond immediately.
