OZ-SH-124D,294 Image
×
Favorite
Compare
Add to RFQ
Share:
TE Connectivity Potter & Brumfield Relays OZ-SH-124D,294
Manufacturer No:
OZ-SH-124D,294
Manufacturer:
TE Connectivity Potter & Brumfield Relays
Package:
Tube
Datasheet:
OZ-SH-124D,294 Datasheet
ECAD Model:
-
Description:
RELAY GEN PURPOSE SPDT 16A 24V
Delivery:
Payment:
Product Attributes
Mounting Type:
Through Hole
Coil Voltage:
24VDC
Contact Form:
SPDT (1 Form C)
Contact Rating (Current):
16 A
Switching Voltage:
240VAC, 24VDC - Max
Coil Current:
29.3 mA
Coil Type:
Non Latching
Features:
-
Termination Style:
PC Pin
Seal Rating:
Sealed - Fully
Coil Insulation:
Class A
Must Operate Voltage:
16.8 VDC
Must Release Voltage:
1.2 VDC
Operate Time:
15 ms
Release Time:
8 ms
Operating Temperature:
-30°C ~ 55°C
Contact Material:
Silver Cadmium Oxide (AgCdO)
Relay Type:
General Purpose
0
Remaining
View Similar
In Stock
UnitPrice:
$4.13
Quantity:
110
