9-1415536-4
9-1415536-4 Image
×
Favorite
Compare
Add to RFQ
Share:
TE Connectivity Potter & Brumfield Relays 9-1415536-4
Manufacturer No:
9-1415536-4
Manufacturer:
TE Connectivity Potter & Brumfield Relays
Package:
Bulk
Datasheet:
9-1415536-4 Datasheet
ECAD Model:
-
Description:
RELAY GEN PURPOSE 3PDT 10A 24V
Delivery:
Payment:
Product Attributes
Mounting Type:
Through Hole
Coil Voltage:
24VDC
Contact Form:
3PDT (3 Form C)
Contact Rating (Current):
10 A
Switching Voltage:
400VAC - Max
Coil Current:
30.9 mA
Coil Type:
Non Latching
Features:
Test Button
Termination Style:
PC Pin
Seal Rating:
Sealed - Flux Protection
Coil Insulation:
Class F
Must Operate Voltage:
18 VDC
Must Release Voltage:
2.4 VDC
Operate Time:
15 ms
Release Time:
10 ms
Operating Temperature:
-40°C ~ 70°C
Contact Material:
Silver Nickel (AgNi)
Relay Type:
General Purpose
0
Remaining
View Similar
In Stock
UnitPrice:
$15.50
Quantity:
38
Please send RFQ , we will respond immediately.
