Please send RFQ , we will respond immediately.
| Part Number | 6600333-5 | 6600333-7 | 6600333-1 |
|---|---|---|---|
| Manufacturer | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors |
| Product Status | Active | Active | Active |
| Connector Usage | - | - | - |
| Connector Type | Header, Male Pins | Header, Male Pins | Receptacle, Female Sockets and Blade Sockets |
| Connector Style | Multi-Beam | Multi-Beam | Multi-Beam |
| Number of Positions | 28 | 22 | 36 |
| Number of Positions Loaded | All | All | All |
| Pitch | 0.100" (2.54mm) | 0.100" (2.54mm) | 0.100" (2.54mm) |
| Number of Rows | 4 | 4 | 4 |
| Number of Columns | - | - | - |
| Mounting Type | Through Hole | Through Hole | Through Hole, Right Angle |
| Termination | Press-Fit | Press-Fit | Solder |
| Contact Layout, Typical | 24 Signal, 4 Power | 16 Signal, 6 Power | 32 Signal, 4 Power |
| Features | Board Lock, Mating Guide | Board Lock, Mating Guide | Board Lock, Guide Pin |
| Contact Finish | - | - | Gold |
| Contact Finish Thickness | - | - | 30.0µin (0.76µm) |
| Color | Black | Black | Black |
