| Part Number | 614-CG1 | 616-CG1 | 624-CG1 | 614-CG1T |
|---|---|---|---|---|
| Manufacturer | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors |
| Product Status | Obsolete | Obsolete | Obsolete | Active |
| Connector Type | Header Strip | Header Strip | Header Strip | Header Strip |
| Contact Type | Slotted | Slotted | Slotted | Slotted |
| Number of Positions | 14 | 16 | 24 | 14 |
| Pitch | 0.100" (2.54mm) | 0.100" (2.54mm) | 0.100" (2.54mm) | 0.100" (2.54mm) |
| Number of Rows | 2 | 2 | 2 | 2 |
| Row Spacing | 0.300" (7.62mm) | 0.300" (7.62mm) | 0.600" (15.24mm) | 0.300" (7.62mm) |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole |
| Termination | Solder | Solder | Solder | Solder |
| Features | - | - | - | - |
| Contact Finish | Gold | Gold | Gold | Tin |
| Contact Finish Thickness | 20.0µin (0.51µm) | 20.0µin (0.51µm) | 20.0µin (0.51µm) | - |
| Color | Black | Black | Black | Black |
