| Part Number | 61060-1 | 61070-1 | 61060-2 | 61960-1 |
|---|---|---|---|---|
| Manufacturer | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors |
| Product Status | Active | Active | Active | Active |
| Terminal Type | Standard | Angled - 90°, Flag | Standard | Angled - 45° |
| Gender | Female | Female | Female | Male |
| Tab Width | 0.110" (2.79mm) | 0.110" (2.79mm) | 0.110" (2.79mm) | 0.187" (4.75mm) |
| Tab Thickness | 0.020" (0.51mm) | 0.020" (0.51mm) | 0.020" (0.51mm) | 0.020" (0.51mm) |
| Tab Length | 0.250" (6.35mm) | - | 0.250" (6.35mm) | - |
| Length - Overall | 0.734" (18.64mm) | - | 0.734" (18.64mm) | - |
| Termination | Crimp | Crimp | Crimp | Screw, Rivet, Stud |
| Wire Gauge | 18-22 AWG | 18-22 AWG | 18-22 AWG | - |
| Insulation | Non-Mating End Insulated | Non-Insulated | Non-Mating End Insulated | Non-Insulated |
| Mounting Type | Free Hanging (In-Line) | Free Hanging (In-Line), Right Angle | Free Hanging (In-Line) | Board, Chassis |
| Features | - | - | - | - |
| Color | Transparent | - | Transparent | - |
| Contact Material | Brass | Brass | Brass | Steel |
| Contact Finish | Tin | Tin | Tin | Nickel |
