| Part Number | 6-1437510-7 | 6-1437514-7 |
|---|---|---|
| Manufacturer | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors |
| Product Status | Obsolete | Active |
| Tail Type | - | No Tail |
| Termination | - | Press-Fit |
| Length - Overall | - | 0.094" (2.39mm) |
| Accepts Pin Diameter | - | 0.016" ~ 0.021" (0.41mm ~ 0.53mm) |
| Accepts Square Pin Size | - | 0.011" x 0.018" (0.28mm x 0.46mm) |
| Pin Hole Diameter | - | 0.026" (0.66mm) |
| Mounting Hole Diameter | - | 0.041" (1.04mm) |
| Flange Diameter | - | - |
| Tail Diameter | - | - |
| Socket Depth | - | - |
| Contact Material | - | Beryllium Copper |
| Contact Finish | - | Tin-Lead |
| Contact Finish Thickness | - | 80.0µin (2.03µm) |
