| Part Number | 55831-2 | 55830-2 |
|---|---|---|
| Manufacturer | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors |
| Product Status | Active | Active |
| Terminal Type | Standard | Standard |
| Stud/Tab Size | 3/8 Stud | 3/8 Stud |
| Terminal Style | Two Stud Holes | Single Stud Hole |
| Tab Thickness | 0.420" (10.67mm) | 0.430" (10.92mm) |
| Length - Overall | 4.200" (106.68mm) | 4.400" (111.76mm) |
| Width - Outer Edges | 1.340" (34.04mm) | 1.420" (36.07mm) |
| Mounting Type | Free Hanging (In-Line) | Free Hanging (In-Line) |
| Termination | Crimp, Barrel | Crimp, Barrel |
| Wire Gauge | 500MCM (kcmil) | 600MCM (kcmil) |
| Insulation | Non-Insulated | Non-Insulated |
| Features | - | - |
| Color | - | - |
