| Part Number | 5225554-6 | 5225557-6 | 5225555-6 |
|---|---|---|---|
| Manufacturer | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors |
| Product Status | Obsolete | Obsolete | Obsolete |
| Connector Style | TNC | TNC | TNC |
| Connector Type | Plug, Male Pin | Jack, Female Socket | Plug, Male Pin |
| Contact Termination | Crimp | Crimp | Crimp |
| Shield Termination | Crimp | Crimp | Crimp |
| Impedance | 50Ohm | 50Ohm | 50Ohm |
| Mounting Type | Free Hanging (In-Line), Right Angle | Panel Mount | Free Hanging (In-Line) |
| Mounting Feature | - | Bulkhead - Front Side Nut | - |
| Cable Group | RG-142, 142A, 142B | RG-142, 142B | RG-142, 142A, 142B |
| Fastening Type | Threaded | Threaded | Threaded |
| Frequency - Max | 11 GHz | 11 GHz | 11 GHz |
| Number of Ports | 1 | 1 | 1 |
| Features | - | - | - |
| Housing Color | Silver | Silver | Silver |
| Ingress Protection | Weatherproof | Weatherproof | Weatherproof |
| Center Contact Material | Brass | - | - |
