| Part Number | 5225392-7 | 5225395-7 | 5225396-7 | 5225398-7 | 5225392-2 |
|---|---|---|---|---|---|
| Manufacturer | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors |
| Product Status | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete |
| Connector Style | N Type | BNC | BNC | BNC | N Type |
| Connector Type | Plug, Male Pin | Plug, Male Pin | Jack, Female Socket | Jack, Female Socket | Plug, Male Pin |
| Contact Termination | Crimp | Crimp | Crimp | Crimp | Crimp |
| Shield Termination | Crimp | Crimp | Crimp | Crimp | Crimp |
| Impedance | 50Ohm | 50Ohm | 50Ohm | 50Ohm | 50Ohm |
| Mounting Type | Free Hanging (In-Line) | Free Hanging (In-Line) | Free Hanging (In-Line) | Panel Mount | Free Hanging (In-Line) |
| Mounting Feature | - | - | - | Bulkhead - Front Side Nut | - |
| Cable Group | RG-58A, 58C | RG-174, 188 | RG-174, 188 | RG-174, 188 | RG-142, 142A, 142B |
| Fastening Type | Threaded | Bayonet Lock | Bayonet Lock | Bayonet Lock | Threaded |
| Frequency - Max | 11 GHz | 4 GHz | 4 GHz | 4 GHz | 11 GHz |
| Number of Ports | 1 | 1 | 1 | 1 | 1 |
| Features | - | - | - | - | - |
| Housing Color | Silver | Silver | Silver | Silver | Silver |
| Ingress Protection | Weatherproof | - | - | - | Weatherproof |
| Center Contact Material | - | Brass | Beryllium Copper | Beryllium Copper | - |
