| Part Number | 50334-3 | 50334-2 |
|---|---|---|
| Manufacturer | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors |
| Product Status | Active | Active |
| Terminal Type | Circular | Circular |
| Stud/Tab Size | 2 Stud | 2 Stud |
| Thickness | 0.018" (0.46mm) | 0.018" (0.46mm) |
| Width - Outer Edges | 0.140" (3.56mm) | 0.140" (3.56mm) |
| Length - Overall | 0.419" (10.64mm) | 0.419" (10.64mm) |
| Mounting Type | Free Hanging (In-Line) | Free Hanging (In-Line) |
| Termination | Crimp | Crimp |
| Wire Gauge | 22-26 AWG | 22-26 AWG |
| Insulation | Non-Insulated | Non-Insulated |
| Features | Brazed Seam, Serrated Termination | Brazed Seam, Serrated Termination |
| Color | - | - |
| Contact Material | Copper | Copper |
| Contact Finish | - | Gold |
