| Part Number | 2195835-1 | 2195835-4 | 2195835-2 | 2195835-5 | 2195835-6 |
|---|---|---|---|---|---|
| Manufacturer | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors |
| Product Status | Active | Active | Active | Active | Active |
| RF Family/Standard | General ISM | General ISM | General ISM | General ISM | General ISM |
| Frequency Group | UHF (300MHz ~ 1GHz) | UHF (300MHz ~ 1GHz) | UHF (300MHz ~ 1GHz) | UHF (300MHz ~ 1GHz) | UHF (300MHz ~ 1GHz) |
| Frequency (Center/Band) | 868MHz, 915MHz | 868MHz, 915MHz | 868MHz, 915MHz | 868MHz, 915MHz | 868MHz, 915MHz |
| Frequency Range | 863MHz ~ 928MHz | 863MHz ~ 928MHz | 863MHz ~ 928MHz | 863MHz ~ 928MHz | 863MHz ~ 928MHz |
| Antenna Type | PCB Trace | PCB Trace | PCB Trace | PCB Trace | PCB Trace |
| Number of Bands | 2 | 2 | 2 | 2 | 2 |
| VSWR | 2.3 | 2.3 | 2.3 | 2.3 | 2.3 |
| Return Loss | - | - | - | - | - |
| Gain | 1.4dBi | -0.9dBi | 1.4dBi | 1.4dBi | 1.4dBi |
| Power - Max | 10 W | 10 W | 10 W | 10 W | 10 W |
| Features | Cable - 50mm | Cable - 200mm | Cable - 100mm | Cable - 50mm | Cable - 100mm |
| Termination | MHF | MHF | MHF | MHF4 | MHF4 |
| Ingress Protection | - | - | - | - | - |
| Mounting Type | Adhesive | Adhesive | Adhesive | Adhesive | Adhesive |
| Height (Max) | 0.008" (0.20mm) | 0.008" (0.20mm) | 0.008" (0.20mm) | 0.008" (0.20mm) | 0.008" (0.20mm) |
| Applications | ISM | ISM | ISM | ISM | ISM |
