Please send RFQ , we will respond immediately.
| Part Number | 2169869-1 | 2169869-2 | 2169869-4 | 2169809-1 | 2169859-1 |
|---|---|---|---|---|---|
| Manufacturer | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors |
| Product Status | Active | Active | Obsolete | Active | Active |
| Connector Usage | - | - | - | - | - |
| Connector Type | Header, Male Pins | Header, Male Blades | Header, Male Blades | Header, Male Pins | Receptacle, Female Blade Sockets |
| Connector Style | Impact | Blade Power | Blade Power | Power | Blade Power |
| Number of Positions | 4 | 4 | 4 | 4 | 4 |
| Number of Positions Loaded | All | All | All | All | All |
| Pitch | - | - | - | - | - |
| Number of Rows | 2 | - | - | 2 | - |
| Number of Columns | 2 | 2 | 2 | 2 | 2 |
| Mounting Type | Board Edge, Through Hole, Right Angle | Board Edge, Through Hole, Right Angle | Board Edge, Through Hole, Right Angle | Through Hole | Through Hole |
| Termination | Press-Fit | Press-Fit | Press-Fit | Press-Fit | Press-Fit |
| Contact Layout, Typical | 4 Power | 4 Power | 4 Power | - | 4 Power |
| Features | Screws | - | - | - | - |
| Contact Finish | Gold | Gold | Gold | Gold | Gold |
| Contact Finish Thickness | 30.0µin (0.76µm) | 30.0µin (0.76µm) | 30.0µin (0.76µm) | 30.0µin (0.76µm) | - |
| Color | Black | Black | Black | Black | Black |
