Please send RFQ , we will respond immediately.
| Part Number | 2118725-2 | 2118729-2 | 2118728-2 | 2118726-2 | 2118725-4 | 2118727-2 | 2118715-2 | 2118720-2 | 2118721-2 | 2118722-2 | 2118723-2 | 2118724-2 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Manufacturer | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors |
| Product Status | Active | Active | Active | Active | Active | Active | Active | Active | Active | Active | Active | Active |
| Type | Cover | Cover | Frame | Frame | Cover | Cover | Cover | Frame | Cover | Frame | Cover | Frame |
| Height - Overall | 0.079" (2.00mm) | 0.079" (2.00mm) | 0.276" (7.00mm) | 0.384" (9.75mm) | 0.079" (2.00mm) | 0.079" (2.00mm) | 0.079" (2.00mm) | 0.236" (6.00mm) | 0.079" (2.00mm) | 0.236" (6.00mm) | 0.079" (2.00mm) | 0.200" (5.08mm) |
| Length - Overall | 1.770" (44.97mm) | 1.756" (44.60mm) | 1.156" (29.36mm) | 1.747" (44.37mm) | 1.770" (44.97mm) | 1.180" (29.96mm) | 0.665" (16.90mm) | 1.260" (32.00mm) | 1.520" (38.60mm) | 1.500" (38.10mm) | 1.470" (37.33mm) | 1.450" (36.83mm) |
| Width - Overall | 1.770" (44.97mm) | 1.224" (31.10mm) | 0.728" (18.50mm) | 1.747" (44.37mm) | 1.770" (44.97mm) | 0.752" (19.10mm) | 0.665" (16.90mm) | 1.260" (32.00mm) | 1.020" (25.90mm) | 1.000" (25.40mm) | 1.346" (34.18mm) | 1.326" (33.68mm) |
| Ventilation | Vented | Vented | - | - | Vented | Vented | Vented | - | Vented | - | Vented | - |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
