| Part Number | 2081970-1 | 2081973-1 | 2081971-1 | 2081977-1 | 2081974-1 | 2081972-1 | 2081570-1 |
|---|---|---|---|---|---|---|---|
| Manufacturer | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors |
| Product Status | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Active |
| Connector Style | 4.3/10 | 4.3/10 | 4.3/10 | 4.3/10 | 4.3/10 | 4.3/10 | 2.92mm |
| Connector Type | Plug, Male Pin | Jack, Female Socket | Plug, Male Pin | Jack, Female Socket | Jack, Female Socket | Plug, Male Pin | Jack, Female Socket |
| Contact Termination | Crimp or Solder | Solder | Crimp or Solder | Solder | Solder | Crimp or Solder | Compression |
| Shield Termination | Clamp | Solder | Clamp | Solder | Solder | Clamp | Screw |
| Impedance | 50Ohm | 50Ohm | 50Ohm | 50Ohm | 50Ohm | 50Ohm | 50Ohm |
| Mounting Type | Free Hanging (In-Line) | Panel Mount | Free Hanging (In-Line), Right Angle | Panel Mount | Panel Mount | Free Hanging (In-Line) | Surface Mount |
| Mounting Feature | - | Flange | - | Flange | Flange | - | Flange |
| Cable Group | 1/2" Super Flex Coaxial | RG-141 | 1/2" Super Flex Coaxial | - | RG-380 | 7/8" Super Flex Coaxial | - |
| Fastening Type | Threaded | Threaded | Threaded | Threaded | Threaded | Threaded | Threaded |
| Frequency - Max | 6 GHz | 6 GHz | 6 GHz | 6 GHz | 6 GHz | 6 GHz | 40 GHz |
| Number of Ports | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Features | - | - | - | - | - | - | - |
| Housing Color | Silver | Silver | Silver | Silver | Silver | Silver | - |
| Ingress Protection | - | - | - | - | - | - | - |
| Center Contact Material | Bronze | Bronze | Bronze | Bronze | Bronze | Bronze | Beryllium Copper |
