| Part Number | 2-328975-2 | 2-328975-3 | 2-328976-2 | 2-328975-1 |
|---|---|---|---|---|
| Manufacturer | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors |
| Product Status | Active | Active | Active | Active |
| Terminal Type | Circular | Circular | Circular | Circular |
| Stud/Tab Size | 1/2 Stud | 1/2 Stud | 1/2 Stud | 1/2 Stud |
| Thickness | 0.031" (0.79mm) | 0.031" (0.79mm) | 0.031" (0.79mm) | 0.031" (0.79mm) |
| Width - Outer Edges | 0.713" (18.11mm) | 0.713" (18.11mm) | 0.713" (18.11mm) | 0.713" (18.11mm) |
| Length - Overall | 1.355" (34.42mm) | 1.355" (34.42mm) | 1.355" (34.42mm) | 1.355" (34.42mm) |
| Mounting Type | Free Hanging (In-Line) | Free Hanging (In-Line) | Free Hanging (In-Line) | Free Hanging (In-Line) |
| Termination | Crimp | Crimp | Crimp | Crimp |
| Wire Gauge | 20 AWG | 18 AWG | 14 AWG | 22 AWG |
| Insulation | Insulated | Insulated | Insulated | Insulated |
| Features | Insulation Restriction, Serrated Termination | Insulation Restriction, Serrated Termination | Insulation Restriction, Serrated Termination | Insulation Restriction, Serrated Termination |
| Color | Red, Red Stripe | Red, White Stripe | Blue, Green Stripe | Red, Green Stripe |
| Contact Material | Copper | Copper | Copper | Copper |
| Contact Finish | Tin | Tin | Tin | Tin |
