Please send RFQ , we will respond immediately.
| Part Number | 180409-2 | 180429-2 | 180439-2 |
|---|---|---|---|
| Manufacturer | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors |
| Product Status | Active | Active | Active |
| Terminal Type | Standard | Angled - 90°, Flag | Standard |
| Gender | Male | Female | Female |
| Tab Width | 0.250" (6.35mm) | 0.250" (6.35mm) | 0.110" (2.79mm) |
| Tab Thickness | 0.032" (0.81mm) | 0.032" (0.81mm) | 0.032" (0.81mm) |
| Tab Length | 0.618" (15.70mm) | - | - |
| Length - Overall | 1.142" (29.00mm) | - | 0.571" (14.50mm) |
| Termination | Crimp | Crimp | Crimp |
| Wire Gauge | 10-11.5 AWG | 13.5-17 AWG | - |
| Insulation | Non-Insulated | Non-Insulated | Non-Insulated |
| Mounting Type | Free Hanging (In-Line) | Free Hanging (In-Line), Right Angle | Free Hanging (In-Line) |
| Features | - | - | - |
| Color | - | - | - |
| Contact Material | - | Brass | Brass |
| Contact Finish | - | Tin | Tin |
