Please send RFQ , we will respond immediately.
| Part Number | 1217089-1 | 1217009-1 | 1217029-1 | 1217080-1 | 1217083-1 | 1217084-1 |
|---|---|---|---|---|---|---|
| Manufacturer | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors |
| Product Status | Active | Active | Active | Active | Active | Active |
| Terminal Type | Angled - 90° | Angled - 90°, Flag | Standard | Standard | Stacked | Stacked |
| Gender | Male | Female | Male | Female | Female and Male | Female and Male |
| Tab Width | 0.110" (2.79mm) | 0.187" (4.75mm) | 0.125" (3.18mm) | 0.205" (5.21mm), 0.250" (6.35mm) | 0.110" (2.79mm) | 0.187" (4.75mm) |
| Tab Thickness | 0.032" (0.81mm) | 0.020" (0.51mm) | 0.020" (0.51mm) | 0.032" (0.81mm) | 0.018" x 0.020" (0.46mm x 0.51mm) / 0.020" (0.51mm) | 0.020" (0.51mm) |
| Tab Length | - | 0.250" (6.35mm) | 0.370" (9.40mm) | 0.330" (8.38mm) | 0.250" (6.35mm) | 0.225" (5.72mm) |
| Length - Overall | - | - | 1.100" (27.94mm) | 0.480" (12.19mm) | 0.600" (15.24mm) | 0.615" (15.62mm) |
| Termination | Solder | Crimp | Crimp | Solder | Crimp | Crimp |
| Wire Gauge | - | 16-20 AWG | 400-1600 CMA | - | 18-22 AWG | 18-22 AWG |
| Insulation | Non-Insulated | Non-Insulated | Non-Insulated | Non-Insulated | Non-Insulated | Non-Insulated |
| Mounting Type | Through Hole, Right Angle | Free Hanging (In-Line), Right Angle | Free Hanging (In-Line) | Through Hole | Free Hanging (In-Line) | Free Hanging (In-Line) |
| Features | - | - | - | - | - | - |
| Color | - | - | - | - | - | - |
| Contact Material | Brass | Brass | Brass | Brass | Brass | Brass |
| Contact Finish | Tin | - | Tin | Tin | - | Tin |
