| Part Number | 1106439-2 | 1106449-2 | 1106419-2 | 1106439-1 |
|---|---|---|---|---|
| Manufacturer | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors |
| Product Status | Obsolete | Active | Active | Active |
| Connector Type | Hood | Hood | Hood | Hood |
| Style | Side Entry | Top Entry | Side Entry | Top Entry |
| Size | 5 | 6 | 3 | 5 |
| Lock Location | Locking Clip (1) on Base Bottom | Locking Clip (1) on Base Bottom | Locking Clip (1) on Base Bottom | Locking Clip (1) on Base Bottom |
| Thread Size | M20 | M32 | M25 | M20 |
| Size / Dimension | 3.130" L x 1.142" W x 2.256" H (79.50mm x 29.00mm x 57.30mm) | 3.681" L x 1.693" W x 2.362" H (93.50mm x 43.00mm x 60.00mm) | 2.362" L x 1.693" W x 1.890" H (60.00mm x 43.00mm x 48.00mm) | 3.130" L x 1.142" W x 2.256" H (79.50mm x 29.00mm x 57.30mm) |
| Housing Color | Gray | Gray | Gray | Gray |
| Features | - | - | - | - |
| Ingress Protection | IP65 - Dust Tight, Water Resistant | IP65 - Dust Tight, Water Resistant | IP65 - Dust Tight, Water Resistant | IP65 - Dust Tight, Water Resistant |
| Housing Material | Aluminum, Die Cast | Aluminum | Aluminum Alloy, Die Cast | Aluminum, Die Cast |
| Housing Finish | Powder Coated | Powder Coated | Powder Coated | Powder Coated |
| Operating Temperature | - | - | - | - |
