| Part Number | 1103073-1 | 1103073-2 | 1103072-1 |
|---|---|---|---|
| Manufacturer | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors |
| Product Status | Active | Obsolete | Active |
| Connector Type | Hood | Hood | Base - Panel Mount |
| Style | Side Entry | Top Entry | Bottom Entry |
| Size | Q | Q | Q |
| Lock Location | Locking Clip (1) on Base Bottom | Locking Clip (1) on Base Bottom | Locking Clip (1) on Base Bottom |
| Thread Size | M25 | M25 | - |
| Size / Dimension | 1.898" L x 1.142" W x 2.126" H (48.20mm x 29.00mm x 54.00mm) | 1.898" L x 1.142" W x 2.126" H (48.20mm x 29.00mm x 54.00mm) | 1.795" L x 1.126" W x 0.740" H (45.60mm x 28.60mm x 18.80mm) |
| Housing Color | Black | Black | Black |
| Features | - | - | - |
| Ingress Protection | IP65 - Dust Tight, Water Resistant | IP65 - Dust Tight, Water Resistant | IP65 - Dust Tight, Water Resistant |
| Housing Material | Polyamide (PA66), Nylon 6/6, Glass Filled | Polyamide (PA66), Nylon 6/6, Glass Filled | Polyamide (PA66), Nylon 6/6, Glass Filled |
| Housing Finish | - | - | - |
| Operating Temperature | - | - | - |
