| Part Number | 1052898-1 | 1052098-1 | 1052897-1 |
|---|---|---|---|
| Manufacturer | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors |
| Product Status | Obsolete | Active | Obsolete |
| Connector Style | SMA | SMA | SMA |
| Connector Type | Receptacle, Female Socket | Plug, Male Pin | Receptacle, Female Socket |
| Contact Termination | Solder Tab | Solder | Solder Tab |
| Shield Termination | Solder | Crimp | Solder |
| Impedance | 50Ohm | 50Ohm | 50Ohm |
| Mounting Type | Panel Mount | Free Hanging (In-Line), Right Angle | Panel Mount |
| Mounting Feature | Flange | - | Flange |
| Cable Group | - | RG-178, 196 | - |
| Fastening Type | Threaded | Threaded | Threaded |
| Frequency - Max | 18 GHz | 12.4 GHz | 18 GHz |
| Number of Ports | 1 | 1 | 1 |
| Features | - | - | - |
| Housing Color | Silver | Silver | Gold |
| Ingress Protection | - | - | - |
| Center Contact Material | Beryllium Copper | Beryllium Copper | Beryllium Copper |
