| Part Number | 1051081-1 | 1051981-1 | 1051001-1 |
|---|---|---|---|
| Manufacturer | TE Connectivity AMP Connectors | TE Connectivity Aerospace, Defense and Marine | TE Connectivity AMP Connectors |
| Product Status | Obsolete | Active | Obsolete |
| Connector Style | SMA | SMA | SMA |
| Connector Type | Jack, Female Socket | Jack, Female Socket | Jack, Female Socket |
| Contact Termination | Solder | Solder | Solder |
| Shield Termination | Solder | Solder | Solder |
| Impedance | 50Ohm | 50Ohm | 50Ohm |
| Mounting Type | Panel Mount | Panel Mount | Panel Mount |
| Mounting Feature | Flange | Bulkhead - Front or Rear Side Nut | Bulkhead - Front Side Nut |
| Cable Group | RG-402 (.141" Semi Rigid) | RG-178 | RG-402 (.141" Semi Rigid) |
| Fastening Type | Threaded | Threaded | Threaded |
| Frequency - Max | 18 GHz | 12.4 GHz | 18 GHz |
| Number of Ports | 1 | 1 | 1 |
| Features | - | Mounting Hardware | - |
| Housing Color | Gold | - | Gold |
| Ingress Protection | - | - | - |
| Center Contact Material | Beryllium Copper | Beryllium Copper | Beryllium Copper |
