| Part Number | 1-6450869-4 | 1-6450869-0 | 1-6450869-3 |
|---|---|---|---|
| Manufacturer | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors |
| Product Status | Active | Active | Active |
| Connector Usage | - | - | - |
| Connector Type | Receptacle, Female Blade Sockets | Receptacle, Female Sockets and Blade Sockets | Receptacle, Female Blade Sockets |
| Connector Style | Multi-Beam | Multi-Beam | Multi-Beam |
| Number of Positions | 40 | 36 | 2 |
| Number of Positions Loaded | All | All | All |
| Pitch | - | - | - |
| Number of Rows | 4 | - | 1 |
| Number of Columns | - | - | - |
| Mounting Type | Through Hole | Through Hole | Through Hole |
| Termination | Press-Fit | Press-Fit | Press-Fit |
| Contact Layout, Typical | 32 Signal, 8 Power | 36 Signal, 8 Power | 2 Power |
| Features | - | - | - |
| Contact Finish | Gold | Gold | Gold |
| Contact Finish Thickness | 30.0µin (0.76µm) | 30.0µin (0.76µm) | 30.0µin (0.76µm) |
| Color | - | - | - |
