| Part Number | 1-221182-6 | 1-221182-0 | 1-221182-2 |
|---|---|---|---|
| Manufacturer | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors | TE Connectivity AMP Connectors |
| Product Status | Active | Obsolete | Obsolete |
| Cable Group | - | - | - |
| Center Conductor Diameter | 0.024" (0.61mm) | 0.035" (0.89mm) | 0.015" (0.38mm) |
| Wire Gauge | - | - | - |
| Contact Termination | Solder | Solder | Solder |
| Pin or Socket | Pin | Pin | Pin |
| Type | BNC | BNC | BNC |
| Mounting Type | Free Hanging (In-Line) | Free Hanging (In-Line) | Free Hanging (In-Line) |
| Impedance | 75Ohm | 75Ohm | 75Ohm |
| Contact Material | Brass | Brass | Brass |
| Contact Finish | Gold | Gold | Gold |
| Contact Finish Thickness | 30.0µin (0.76µm) | 30.0µin (0.76µm) | 30.0µin (0.76µm) |
| Features | - | - | - |
| Board Thickness | - | - | - |
