| Part Number | PCMB104T-2R2MS | PCMB104E-2R2MS | PCMB104T-2R0MS |
|---|---|---|---|
| Manufacturer | Susumu | Susumu | Susumu |
| Product Status | Active | Active | Active |
| Type | - | - | - |
| Material - Core | - | - | - |
| Inductance | 2.2 µH | 2.2 µH | 2 µH |
| Tolerance | ±20% | ±20% | ±20% |
| Current Rating (Amps) | 12 A | 14 A | 14 A |
| Current - Saturation (Isat) | 18A | 16A | 14A |
| Shielding | Unshielded | Unshielded | Unshielded |
| DC Resistance (DCR) | 7mOhm Max | 7mOhm Max | 5.8mOhm Max |
| Q @ Freq | - | - | - |
| Frequency - Self Resonant | - | - | - |
| Ratings | - | - | - |
| Operating Temperature | - | - | - |
| Inductance Frequency - Test | 100 kHz | 100 kHz | 100 kHz |
| Features | - | - | - |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | Nonstandard | Nonstandard | Nonstandard |
| Supplier Device Package | - | - | - |
| Size / Dimension | 0.433" L x 0.394" W (11.00mm x 10.00mm) | 0.453" L x 0.394" W (11.50mm x 10.00mm) | 0.433" L x 0.394" W (11.00mm x 10.00mm) |
| Height - Seated (Max) | 0.150" (3.80mm) | 0.130" (3.30mm) | 0.150" (3.80mm) |
