| Part Number | PAT0510S-C-0DB-T10 | PAT0510S-C-8DB-T10 | PAT0510S-C-6DB-T10 | PAT0510S-C-1DB-T10 | PAT0510S-C-3DB-T10 | PAT0510S-C-2DB-T10 | PAT0510S-C-5DB-T10 | PAT0510S-C-4DB-T10 | PAT0510S-C-7DB-T10 | PAT0510S-C-10DB-T10 | PAT0510S-C-9DB-T10 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Manufacturer | Susumu | Susumu | Susumu | Susumu | Susumu | Susumu | Susumu | Susumu | Susumu | Susumu | Susumu |
| Product Status | Active | Active | Active | Active | Active | Active | Active | Active | Active | Active | Active |
| Attenuation Value | 0dB | 8dB | 6dB | 1dB | 3dB | 2dB | 5dB | 4dB | 7dB | 10dB | 9dB |
| Frequency Range | 0 Hz ~ 10 GHz | 0 Hz ~ 10 GHz | 0 Hz ~ 10 GHz | 0 Hz ~ 10 GHz | 0 Hz ~ 10 GHz | 0 Hz ~ 10 GHz | 0 Hz ~ 10 GHz | 0 Hz ~ 10 GHz | 0 Hz ~ 10 GHz | 0 Hz ~ 10 GHz | 0 Hz ~ 10 GHz |
| Power (Watts) | 32mW | 32mW | 32mW | 32mW | 32mW | 32mW | 32mW | 32mW | 32mW | 32mW | 32mW |
| Impedance | 50 Ohms | 50 Ohms | 50 Ohms | 50 Ohms | 50 Ohms | 50 Ohms | 50 Ohms | 50 Ohms | 50 Ohms | 50 Ohms | 50 Ohms |
| Package / Case | 0402 (1005 Metric) | 0402 (1005 Metric) | 0402 (1005 Metric) | 0402 (1005 Metric) | 0402 (1005 Metric) | 0402 (1005 Metric) | 0402 (1005 Metric) | 0402 (1005 Metric) | 0402 (1005 Metric) | 0402 (1005 Metric) | 0402 (1005 Metric) |
