Please send RFQ , we will respond immediately.
| Part Number | ATS2012-7DB-T05 | ATS2012-8DB-T05 | ATS2012-9DB-T05 | ATS2012-0DB-T05 | ATS2012-1DB-T05 | ATS2012-2DB-T05 | ATS2012-3DB-T05 | ATS2012-4DB-T05 | ATS2012-5DB-T05 | ATS2012-6DB-T05 |
|---|---|---|---|---|---|---|---|---|---|---|
| Manufacturer | Susumu | Susumu | Susumu | Susumu | Susumu | Susumu | Susumu | Susumu | Susumu | Susumu |
| Product Status | Active | Active | Active | Active | Active | Active | Active | Active | Active | Active |
| Attenuation Value | 7dB | 8dB | 9dB | 0dB | 1dB | 2dB | 3dB | 4dB | 5dB | 6dB |
| Frequency Range | 0 Hz ~ 30 GHz | 0 Hz ~ 30 GHz | 0 Hz ~ 30 GHz | 0 Hz ~ 30 GHz | 0 Hz ~ 30 GHz | 0 Hz ~ 30 GHz | 0 Hz ~ 30 GHz | 0 Hz ~ 30 GHz | 0 Hz ~ 30 GHz | 0 Hz ~ 30 GHz |
| Power (Watts) | 100mW | 100mW | 100mW | 100mW | 100mW | 100mW | 100mW | 100mW | 100mW | 100mW |
| Impedance | 50 Ohms | 50 Ohms | 50 Ohms | 50 Ohms | 50 Ohms | 50 Ohms | 50 Ohms | 50 Ohms | 50 Ohms | 50 Ohms |
| Package / Case | 0805 (2012 Metric) | 0805 (2012 Metric) | 0805 (2012 Metric) | 0805 (2012 Metric) | 0805 (2012 Metric) | 0805 (2012 Metric) | 0805 (2012 Metric) | 0805 (2012 Metric) | 0805 (2012 Metric) | 0805 (2012 Metric) |
