| Part Number | TSV358AIST | TSV358IST | TSV358AIDT |
|---|---|---|---|
| Manufacturer | STMicroelectronics | STMicroelectronics | STMicroelectronics |
| Product Status | Active | Active | Active |
| Amplifier Type | General Purpose | General Purpose | General Purpose |
| Number of Circuits | 2 | 2 | 2 |
| Output Type | Rail-to-Rail | Rail-to-Rail | Rail-to-Rail |
| Slew Rate | 0.6V/µs | 0.6V/µs | 0.6V/µs |
| Gain Bandwidth Product | 1.4 MHz | 1.4 MHz | 1.4 MHz |
| -3db Bandwidth | - | - | - |
| Current - Input Bias | 70 nA | 70 nA | 70 nA |
| Voltage - Input Offset | 100 µV | 200 µV | 100 µV |
| Current - Supply | 500µA | 500µA | 500µA |
| Current - Output / Channel | 80 mA | 80 mA | 80 mA |
| Voltage - Supply Span (Min) | 2.5 V | 2.5 V | 2.5 V |
| Voltage - Supply Span (Max) | 6 V | 6 V | 6 V |
| Operating Temperature | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-MiniSO | 8-MiniSO | 8-SO |
