| Part Number | T410-800H | T410-800T | T410-600H | T410-700H | T410-800B |
|---|---|---|---|---|---|
| Manufacturer | STMicroelectronics | STMicroelectronics | STMicroelectronics | STMicroelectronics | STMicroelectronics |
| Product Status | Active | Active | Active | Obsolete | Obsolete |
| Triac Type | Logic - Sensitive Gate | Logic - Sensitive Gate | Logic - Sensitive Gate | Logic - Sensitive Gate | Logic - Sensitive Gate |
| Voltage - Off State | 800 V | 800 V | 600 V | 700 V | 800 V |
| Current - On State (It (RMS)) (Max) | 4 A | 4 A | 4 A | 4 A | 4 A |
| Voltage - Gate Trigger (Vgt) (Max) | 1.3 V | 1.3 V | 1.3 V | 1.3 V | 1.3 V |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 30A, 31A | 30A, 31A | 30A, 31A | 30A, 31A | 30A, 31A |
| Current - Gate Trigger (Igt) (Max) | 10 mA | 10 mA | 10 mA | 10 mA | 10 mA |
| Current - Hold (Ih) (Max) | 15 mA | 15 mA | 15 mA | 15 mA | 15 mA |
| Configuration | Single | Single | Single | Single | Single |
| Operating Temperature | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Surface Mount |
| Package / Case | TO-251-3 Short Leads, IPak, TO-251AA | TO-220-3 | TO-251-3 Short Leads, IPak, TO-251AA | TO-251-3 Short Leads, IPak, TO-251AA | TO-252-3, DPak (2 Leads + Tab), SC-63 |
| Supplier Device Package | TO-251 (IPAK) | TO-220AB | TO-251 (IPAK) | I-PAK | DPAK |
