| Part Number | T1235T-6I | T1235T-8I | T1635T-6I | T1225T-6I | T1235H-6I |
|---|---|---|---|---|---|
| Manufacturer | STMicroelectronics | STMicroelectronics | STMicroelectronics | STMicroelectronics | STMicroelectronics |
| Product Status | Active | Active | Active | Active | Active |
| Triac Type | Alternistor - Snubberless | Alternistor - Snubberless | Alternistor - Snubberless | Alternistor - Snubberless | Alternistor - Snubberless |
| Voltage - Off State | 600 V | 800 V | 600 V | 600 V | 600 V |
| Current - On State (It (RMS)) (Max) | 12 A | 12 A | 16 A | 12 A | 12 A |
| Voltage - Gate Trigger (Vgt) (Max) | 1.3 V | 1.3 V | 1.3 V | 1.3 V | 1 V |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 90A, 95A | 95A, 90A | 120A, 126A | 90A, 95A | 120A, 126A |
| Current - Gate Trigger (Igt) (Max) | 35 mA | 35 mA | 35 mA | 25 mA | 35 mA |
| Current - Hold (Ih) (Max) | 30 mA | 40 mA | 40 mA | 20 mA | 35 mA |
| Configuration | Single | Single | Single | Single | Single |
| Operating Temperature | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) | -40°C ~ 150°C (TJ) |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | TO-220-3 | TO-220-3 | TO-220-3 | TO-220-3 | TO-220-3 |
| Supplier Device Package | TO-220AB Insulated | TO-220AB Insulated | TO-220 | TO-220AB Insulated | TO-220 |
