Please send RFQ , we will respond immediately.
| Part Number | STW36N60M6 | STW33N60M6 |
|---|---|---|
| Manufacturer | STMicroelectronics | STMicroelectronics |
| Product Status | Active | Active |
| FET Type | N-Channel | N-Channel |
| Technology | MOSFET (Metal Oxide) | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 600 V | 600 V |
| Current - Continuous Drain (Id) @ 25°C | 30A (Tc) | 25A (Tj) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V | - |
| Rds On (Max) @ Id, Vgs | 99mOhm @ 15A, 10V | - |
| Vgs(th) (Max) @ Id | 4.75V @ 250µA | - |
| Gate Charge (Qg) (Max) @ Vgs | 44.3 nC @ 10 V | - |
| Vgs (Max) | ±25V | - |
| Input Capacitance (Ciss) (Max) @ Vds | 1960 pF @ 100 V | - |
| FET Feature | - | - |
| Power Dissipation (Max) | 208W (Tc) | - |
| Operating Temperature | -55°C ~ 150°C (TJ) | - |
| Mounting Type | Through Hole | Through Hole |
| Supplier Device Package | TO-247-3 | TO-247-3 |
| Package / Case | TO-247-3 | TO-247-3 |
