Please send RFQ , we will respond immediately.
| Part Number | STPSC10H12WL | STPSC15H12WL | STPSC20H12WL |
|---|---|---|---|
| Manufacturer | STMicroelectronics | STMicroelectronics | STMicroelectronics |
| Product Status | Active | Active | Active |
| Diode Type | Silicon Carbide Schottky | Silicon Carbide Schottky | Silicon Carbide Schottky |
| Voltage - DC Reverse (Vr) (Max) | 1200 V | 1200 V | 1200 V |
| Current - Average Rectified (Io) | 10A | 15A | 20A |
| Voltage - Forward (Vf) (Max) @ If | 1.5 V @ 10 A | 1.5 V @ 15 A | 1.5 V @ 20 A |
| Speed | No Recovery Time > 500mA (Io) | No Recovery Time > 500mA (Io) | No Recovery Time > 500mA (Io) |
| Reverse Recovery Time (trr) | 0 ns | 0 ns | 0 ns |
| Current - Reverse Leakage @ Vr | 60 µA @ 1200 V | 90 µA @ 1200 V | 120 µA @ 1200 V |
| Capacitance @ Vr, F | 725pF @ 0V, 1MHz | 1200pF @ 0V, 1MHz | 1650pF @ 0V, 1MHz |
| Mounting Type | Through Hole | Through Hole | Through Hole |
| Package / Case | DO-247-2 (Straight Leads) | DO-247-2 (Straight Leads) | DO-247-2 (Straight Leads) |
| Supplier Device Package | DO-247 | DO-247 | DO-247 |
| Operating Temperature - Junction | -40°C ~ 175°C | -40°C ~ 175°C | -40°C ~ 175°C |
