| Part Number | STPS30M120STN | STPS30SM120STN | STPS20M120STN |
|---|---|---|---|
| Manufacturer | STMicroelectronics | STMicroelectronics | STMicroelectronics |
| Product Status | Obsolete | Obsolete | Obsolete |
| Diode Type | Schottky | Schottky | Schottky |
| Voltage - DC Reverse (Vr) (Max) | 120 V | 120 V | 120 V |
| Current - Average Rectified (Io) | 30A | 30A | 20A |
| Voltage - Forward (Vf) (Max) @ If | 900 mV @ 30 A | 950 mV @ 30 A | 840 mV @ 20 A |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | Fast Recovery =< 500ns, > 200mA (Io) | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | - | - | - |
| Current - Reverse Leakage @ Vr | 345 µA @ 120 V | 275 µA @ 120 V | 275 µA @ 120 V |
| Capacitance @ Vr, F | - | - | - |
| Mounting Type | Through Hole | Through Hole | Through Hole |
| Package / Case | TO-220-3 | TO-220-3 | TO-220-3 |
| Supplier Device Package | TO-220AB Narrow Leads | TO-220AB Narrow Leads | TO-220AB Narrow Leads |
| Operating Temperature - Junction | 150°C (Max) | 150°C (Max) | 150°C (Max) |
