| Part Number | STL8DN6LF3 | STL7DN6LF3 |
|---|---|---|
| Manufacturer | STMicroelectronics | STMicroelectronics |
| Product Status | Active | Active |
| FET Type | 2 N-Channel (Dual) | 2 N-Channel (Dual) |
| FET Feature | Logic Level Gate | Logic Level Gate |
| Drain to Source Voltage (Vdss) | 60V | 60V |
| Current - Continuous Drain (Id) @ 25°C | 20A | 20A |
| Rds On (Max) @ Id, Vgs | 30mOhm @ 4A, 10V | 43mOhm @ 3A, 10V |
| Vgs(th) (Max) @ Id | 2.5V @ 250µA | 3V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs | 13nC @ 10V | 8.8nC @ 10V |
| Input Capacitance (Ciss) (Max) @ Vds | 668pF @ 25V | 432pF @ 25V |
| Power - Max | 65W | 52W |
| Operating Temperature | -55°C ~ 175°C (TJ) | -55°C ~ 175°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | 8-PowerVDFN | 8-PowerVDFN |
| Supplier Device Package | PowerFlat™ (5x6) | PowerFlat™ (5x6) |
