STMicroelectronics-STGP3HF60HD - Transistors - IGBTs - Single Product Specifications and Latest Quotes

IGBT Type:	-
Voltage - Collector Emitter Breakdown (Max):	600 V
Current - Collector (Ic) (Max):	7.5 A
Current - Collector Pulsed (Icm):	18 A
Vce(on) (Max) @ Vge, Ic:	2.95V @ 15V, 1.5A
Power - Max:	38 W
Switching Energy:	19µJ (on), 12µJ (off)
Input Type:	Standard
Gate Charge:	12 nC
Td (on/off) @ 25°C:	11ns/60ns
Test Condition:	400V, 1.5A, 100Ohm, 15V
Reverse Recovery Time (trr):	85 ns
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Through Hole
Package / Case:	TO-220-3
Supplier Device Package:	TO-220

STMicroelectronics STGP3HF60HD
