| Part Number | ST62E60CF1 | ST62E65CF1 | ST62E20CF1 |
|---|---|---|---|
| Manufacturer | STMicroelectronics | STMicroelectronics | STMicroelectronics |
| Product Status | Obsolete | Obsolete | Obsolete |
| Core Processor | ST6 | ST6 | ST6 |
| Core Size | 8-Bit | 8-Bit | 8-Bit |
| Speed | 8MHz | 8MHz | 8MHz |
| Connectivity | SPI | SPI | - |
| Peripherals | LED, LVD, POR, WDT | LED, LVD, POR, WDT | LVD, POR, WDT |
| Number of I/O | 13 | 21 | 12 |
| Program Memory Size | 3.8KB (3.8K x 8) | 3.8KB (3.8K x 8) | 4KB (4K x 8) |
| Program Memory Type | EPROM, UV | EPROM, UV | EPROM, UV |
| EEPROM Size | 128 x 8 | 128 x 8 | - |
| RAM Size | 128 x 8 | 128 x 8 | 64 x 8 |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 6V | 3V ~ 6V | 3V ~ 6V |
| Data Converters | A/D 7x8b | A/D 13x8b | A/D 8x8b |
| Oscillator Type | Internal | Internal | Internal |
| Operating Temperature | 0°C ~ 70°C (TA) | 0°C ~ 70°C (TA) | 0°C ~ 70°C (TA) |
| Mounting Type | Through Hole | Through Hole | Through Hole |
| Package / Case | 20-CDIP (0.300", 7.62mm) Window | 28-CDIP (0.600", 15.24mm) Window | 20-CDIP (0.300", 7.62mm) Window |
| Supplier Device Package | - | - | - |
