| Part Number | SMB6F58A | SMB6F58AY | SMB6F48A |
|---|---|---|---|
| Manufacturer | STMicroelectronics | STMicroelectronics | STMicroelectronics |
| Product Status | Active | Active | Active |
| Type | Zener | Zener | Zener |
| Unidirectional Channels | 1 | 1 | 1 |
| Bidirectional Channels | - | - | - |
| Voltage - Reverse Standoff (Typ) | 58V (Max) | 58V (Max) | 48V (Max) |
| Voltage - Breakdown (Min) | 64.6V | 64.6V | 53.2V |
| Voltage - Clamping (Max) @ Ipp | 121V | 121V | 100V |
| Current - Peak Pulse (10/1000µs) | 33A (8/20µs) | 33A (8/20µs) | 40A (8/20µs) |
| Power - Peak Pulse | 600W | 600W | 600W |
| Power Line Protection | No | No | No |
| Applications | General Purpose | Automotive | General Purpose |
| Capacitance @ Frequency | - | - | - |
| Operating Temperature | -55°C ~ 175°C (TJ) | -55°C ~ 175°C (TJ) | -55°C ~ 175°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | DO-221AA, SMB Flat Leads | DO-221AA, SMB Flat Leads | DO-221AA, SMB Flat Leads |
| Supplier Device Package | SMBflat | SMBflat | SMBflat |
