| Part Number | PD55035S-E | PD85035S-E | PD55015S-E | PD55025S-E | PD55035-E |
|---|---|---|---|---|---|
| Manufacturer | STMicroelectronics | STMicroelectronics | STMicroelectronics | STMicroelectronics | STMicroelectronics |
| Product Status | Obsolete | Active | Active | Active | Obsolete |
| Transistor Type | LDMOS | LDMOS | LDMOS | LDMOS | LDMOS |
| Frequency | 500MHz | 870MHz | 500MHz | 500MHz | 500MHz |
| Gain | 16.9dB | 17dB | 14dB | 14.5dB | 16.9dB |
| Voltage - Test | 12.5 V | 13.6 V | 12.5 V | 12.5 V | 12.5 V |
| Current Rating (Amps) | 7A | 8A | 5A | 7A | 7A |
| Noise Figure | - | - | - | - | - |
| Current - Test | 200 mA | 350 mA | 150 mA | 200 mA | 200 mA |
| Power - Output | 35W | 15W | 15W | 25W | 35W |
| Voltage - Rated | 40 V | 40 V | 40 V | 40 V | 40 V |
| Package / Case | PowerSO-10 Exposed Bottom Pad | PowerSO-10 Exposed Bottom Pad | PowerSO-10 Exposed Bottom Pad | PowerSO-10 Exposed Bottom Pad | PowerSO-10RF Exposed Bottom Pad (2 Formed Leads) |
| Supplier Device Package | PowerSO-10RF (Straight Lead) | PowerSO-10RF (Straight Lead) | PowerSO-10RF (Straight Lead) | PowerSO-10RF (Straight Lead) | PowerSO-10RF (Formed Lead) |
