| Part Number | PD55015STR-E | PD55015TR-E | PD55035STR-E | PD85015STR-E | PD55025STR-E |
|---|---|---|---|---|---|
| Manufacturer | STMicroelectronics | STMicroelectronics | STMicroelectronics | STMicroelectronics | STMicroelectronics |
| Product Status | Active | Active | Not For New Designs | Obsolete | Obsolete |
| Transistor Type | LDMOS | LDMOS | LDMOS | LDMOS | LDMOS |
| Frequency | 500MHz | 500MHz | 500MHz | 870MHz | 500MHz |
| Gain | 14dB | 14dB | 16.9dB | 16dB | 14.5dB |
| Voltage - Test | 12.5 V | 12.5 V | 12.5 V | 13.6 V | 12.5 V |
| Current Rating (Amps) | 5A | 5A | 7A | 5A | 7A |
| Noise Figure | - | - | - | - | - |
| Current - Test | 150 mA | 150 mA | 200 mA | 150 mA | 200 mA |
| Power - Output | 15W | 15W | 35W | 15W | 25W |
| Voltage - Rated | 40 V | 40 V | 40 V | 40 V | 40 V |
| Package / Case | PowerSO-10 Exposed Bottom Pad | PowerSO-10RF Exposed Bottom Pad (2 Formed Leads) | PowerSO-10 Exposed Bottom Pad | PowerSO-10RF Exposed Bottom Pad (2 Straight Leads) | PowerSO-10 Exposed Bottom Pad |
| Supplier Device Package | PowerSO-10RF (Straight Lead) | PowerSO-10RF (Formed Lead) | PowerSO-10RF (Straight Lead) | PowerSO-10RF (Straight Lead) | PowerSO-10RF (Straight Lead) |
