Please send RFQ , we will respond immediately.
| Part Number | LD39130SJ25R | LD39130SJ29R | LD39030SJ25R |
|---|---|---|---|
| Manufacturer | STMicroelectronics | STMicroelectronics | STMicroelectronics |
| Product Status | Active | Active | Active |
| Output Configuration | Positive | Positive | Positive |
| Output Type | Fixed | Fixed | Fixed |
| Number of Regulators | 1 | 1 | 1 |
| Voltage - Input (Max) | 5.5V | 5.5V | 5.5V |
| Voltage - Output (Min/Fixed) | 2.5V | 2.9V | 2.5V |
| Voltage - Output (Max) | - | - | - |
| Voltage Dropout (Max) | 0.3V @ 300mA (Typ) | 0.3V @ 300mA (Typ) | 0.3V @ 300mA |
| Current - Output | 300mA | 300mA | 300mA |
| Current - Quiescent (Iq) | 45 µA | 45 µA | 50 µA |
| Current - Supply (Max) | - | - | 85 µA |
| PSRR | 70dB ~ 65dB (1kHz ~ 10kHz) | 70dB ~ 65dB (1kHz ~ 10kHz) | 62dB (1kHz ~ 10kHz) |
| Control Features | Enable | Enable | Enable |
| Protection Features | Over Current, Over Temperature, Soft Start | Over Current, Over Temperature, Soft Start | Over Current, Over Temperature, Soft Start |
| Operating Temperature | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 4-UFBGA, FCBGA | 4-UFBGA, FCBGA | 4-UFBGA, FCBGA |
| Supplier Device Package | 4-FlipChip (.69x.69) | 4-FlipChip (.69x.69) | 4-Flipchip (0.79x0.79) |
