| Part Number | L4995RJ | L4995RK | L4995AJ | L4995J |
|---|---|---|---|---|
| Manufacturer | STMicroelectronics | STMicroelectronics | STMicroelectronics | STMicroelectronics |
| Product Status | Active | Obsolete | Active | Active |
| Output Configuration | Positive | Positive | Positive | Positive |
| Output Type | Fixed | Fixed | Fixed | Fixed |
| Number of Regulators | 1 | 1 | 1 | 1 |
| Voltage - Input (Max) | 31V | 31V | 31V | 31V |
| Voltage - Output (Min/Fixed) | 5V | 5V | 5V | 5V |
| Voltage - Output (Max) | - | - | - | - |
| Voltage Dropout (Max) | 0.5V @ 400mA | 0.5V @ 400mA | 0.5V @ 400mA | 0.5V @ 400mA |
| Current - Output | 500mA | 500mA | 500mA | 500mA |
| Current - Quiescent (Iq) | 160 µA | 160 µA | 160 µA | 160 µA |
| Current - Supply (Max) | 2.7 mA | 2.7 mA | 2.7 mA | 2.7 mA |
| PSRR | 55dB (100Hz) | 55dB (100Hz) | 55dB (100Hz) | 55dB (100Hz) |
| Control Features | Reset | Reset | Enable, Reset | Enable, Reset, Watchdog |
| Protection Features | Over Temperature, Short Circuit | Over Temperature, Short Circuit | Over Temperature, Short Circuit | Over Temperature, Short Circuit |
| Operating Temperature | -40°C ~ 150°C | -40°C ~ 150°C | -40°C ~ 150°C | -40°C ~ 150°C |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | PowerSSO-12 | 24-PowerBSOP (0.295", 7.50mm Width) | PowerSSO-12 | PowerSSO-12 |
| Supplier Device Package | PowerSSO-12 | PowerSSO-24 | PowerSSO-12 | PowerSSO-12 |
