Please send RFQ , we will respond immediately.
| Part Number | ESDALC6V1M6 | ESDALC6V1P6 | ESDALC6V1M3 |
|---|---|---|---|
| Manufacturer | STMicroelectronics | STMicroelectronics | STMicroelectronics |
| Product Status | Obsolete | Active | Active |
| Type | Zener | Zener | Zener |
| Unidirectional Channels | 4 | 4 | 2 |
| Bidirectional Channels | - | - | - |
| Voltage - Reverse Standoff (Typ) | 3V | 3V | 5V |
| Voltage - Breakdown (Min) | 6.1V | 6.1V | 6.1V |
| Voltage - Clamping (Max) @ Ipp | - | - | - |
| Current - Peak Pulse (10/1000µs) | - | - | - |
| Power - Peak Pulse | 30W | 30W | 30W |
| Power Line Protection | No | No | No |
| Applications | General Purpose | General Purpose | General Purpose |
| Capacitance @ Frequency | 12pF @ 1MHz | - | 11pF @ 1MHz |
| Operating Temperature | -40°C ~ 125°C (TJ) | -40°C ~ 150°C (TJ) | -40°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 6-UFDFN | SOT-563, SOT-666 | SC-101, SOT-883 |
| Supplier Device Package | 6-µQFN (1.45x1.0) | SOT-666IP | SOT-883 |
