| Part Number | SMP1325-087LF | SMP1345-087LF | SMP1324-087LF | SMP1325-085LF |
|---|---|---|---|---|
| Manufacturer | Skyworks Solutions Inc. | Skyworks Solutions Inc. | Skyworks Solutions Inc. | Skyworks Solutions Inc. |
| Product Status | Active | Active | Active | Active |
| Diode Type | PIN - Single | PIN - Single | PIN - Single | PIN - Single |
| Voltage - Peak Reverse (Max) | - | - | - | 200V |
| Current - Max | 200 mA | 200 mA | 200 mA | 200 mA |
| Capacitance @ Vr, F | 0.6pF @ 20V, 1MHz | 0.2pF @ 5V, 1MHz | 1.5pF @ 30V, 1MHz | 0.65pF @ 20V, 1MHz |
| Resistance @ If, F | 550mOhm @ 100mA, 100MHz | 2Ohm @ 10mA, 100MHz | 750mOhm @ 50mA, 100MHz | 500mOhm @ 100mA, 100MHz |
| Power Dissipation (Max) | 2 W | 500 mW | 2 W | 4.5 W |
| Operating Temperature | -55°C ~ 175°C (TJ) | -55°C ~ 175°C (TJ) | -55°C ~ 175°C (TJ) | -40°C ~ 150°C (TA) |
| Package / Case | 2-VSFN Exposed Pad | 2-VSFN Exposed Pad | 2-VSFN Exposed Pad | 2-VDFN Exposed Pad |
| Supplier Device Package | 2-QFN (2x2) | 2-QFN (2x2) | 2-QFN (2x2) | 3-QFN (2x2) |
