| Part Number | AAT4901IJS-1-T1 | AAT4901IJS-3-T1 |
|---|---|---|
| Manufacturer | Skyworks Solutions Inc. | Skyworks Solutions Inc. |
| Product Status | Obsolete | Obsolete |
| Output Configuration | Half Bridge (2) | Half Bridge (2) |
| Applications | DC Motors, Solenoids, Transformers | DC Motors, Solenoids, Transformers |
| Interface | Logic | Logic |
| Load Type | Inductive | Inductive |
| Technology | Power MOSFET | Power MOSFET |
| Rds On (Typ) | 200mOhm LS, 240mOhm HS | 200mOhm LS, 240mOhm HS |
| Current - Output / Channel | 700mA | 700mA |
| Current - Peak Output | 3A | 3A |
| Voltage - Supply | 2V ~ 5.5V | 2V ~ 5.5V |
| Voltage - Load | 2V ~ 5.5V | 2V ~ 5.5V |
| Operating Temperature | -40°C ~ 150°C (TJ) | -40°C ~ 150°C (TJ) |
| Features | - | - |
| Fault Protection | Over Temperature, Shoot-Through | Over Temperature, Shoot-Through |
| Mounting Type | Surface Mount | Surface Mount |
| Package / Case | 8-TFSOJ (0.069", 1.75mm Width) | 8-TFSOJ (0.069", 1.75mm Width) |
| Supplier Device Package | 8-SC70JW | 8-SC70JW |
