| Part Number | WGM110E1MV2 | WGM110E1MV2R | WGM110A1MV2 |
|---|---|---|---|
| Manufacturer | Silicon Labs | Silicon Labs | Silicon Labs |
| Product Status | Last Time Buy | Last Time Buy | Last Time Buy |
| RF Family/Standard | WiFi | WiFi | WiFi |
| Protocol | 802.11b/g/n | 802.11b/g/n | 802.11b/g/n |
| Modulation | - | - | - |
| Frequency | 2.4GHz | 2.4GHz | 2.4GHz |
| Data Rate | 72.2Mbps | 72.2Mbps | 72.2Mbps |
| Power - Output | 16dBm | 16dBm | 16dBm |
| Sensitivity | -98dBm | -98dBm | -98dBm |
| Serial Interfaces | I²C, SPI, UART, USB | I²C, SPI, UART, USB | I²C, SPI, UART, USB |
| Antenna Type | Antenna Not Included, U.FL | Antenna Not Included, U.FL | Integrated, Chip |
| Utilized IC / Part | - | - | - |
| Memory Size | 1MB Flash, 128kB RAM | 1MB Flash, 128kB RAM | 1MB Flash, 128kB RAM |
| Voltage - Supply | 2.7V ~ 4.8V | 2.7V ~ 4.8V | 2.7V ~ 4.8V |
| Current - Receiving | 81mA | 81mA | 81mA |
| Current - Transmitting | 261mA | 261mA | 261mA |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Operating Temperature | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C |
| Package / Case | Module | Module | Module |
