| Part Number | TS1003IG5T | TS1005IG5T | TS1003IG5 |
|---|---|---|---|
| Manufacturer | Silicon Labs | Silicon Labs | Silicon Labs |
| Product Status | Obsolete | Obsolete | Obsolete |
| Amplifier Type | General Purpose | General Purpose | General Purpose |
| Number of Circuits | 1 | 1 | 1 |
| Output Type | Rail-to-Rail | Rail-to-Rail | Rail-to-Rail |
| Slew Rate | 1.5V/µs | 7.5V/µs | 1.5V/µs |
| Gain Bandwidth Product | 4 kHz | 20 kHz | 4 kHz |
| -3db Bandwidth | - | - | - |
| Current - Input Bias | 2 pA | 2 pA | 2 pA |
| Voltage - Input Offset | 800 µV | 800 µV | 800 µV |
| Current - Supply | 600nA | 1.3µA | 600nA |
| Current - Output / Channel | 15 mA | 15 mA | 15 mA |
| Voltage - Supply Span (Min) | 0.8 V | 0.8 V | 0.8 V |
| Voltage - Supply Span (Max) | 5.5 V | 5.5 V | 5.5 V |
| Operating Temperature | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | SC-74A, SOT-753 | SC-74A, SOT-753 | SC-74A, SOT-753 |
| Supplier Device Package | SOT-23-5 | SOT-23-5 | SOT-23-5 |
