| Part Number | EFR32MG14P732F256IM32-B | EFR32MG14P732F256IM32-BR | EFR32MG14P732F256GM32-B |
|---|---|---|---|
| Manufacturer | Silicon Labs | Silicon Labs | Silicon Labs |
| Product Status | Not For New Designs | Not For New Designs | Not For New Designs |
| Type | - | - | TxRx + MCU |
| RF Family/Standard | - | - | 802.15.4, Bluetooth |
| Protocol | - | - | Bluetooth v5.0, Thread, Zigbee® |
| Modulation | - | - | 2-FSK, 4-FSK, 2-GFSK, 4-GFSK, ASK, BPSK, DBPSK, DSSS, GFSK, GMSK, MSK, OOK, O-QPSK |
| Frequency | - | - | 2.4GHz |
| Data Rate (Max) | - | - | 2Mbps |
| Power - Output | - | - | 19dBm |
| Sensitivity | - | - | -126.2dBm |
| Memory Size | - | - | 256kB Flash, 32kB RAM |
| Serial Interfaces | - | - | I²C, I²S, SPI, IrDA, UART, USART |
| GPIO | - | - | 16 |
| Voltage - Supply | - | - | 1.8V ~ 3.8V |
| Current - Receiving | - | - | 8.4mA ~ 11.1mA |
| Current - Transmitting | - | - | 8.5mA ~ 131mA |
| Operating Temperature | - | - | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 32-VFQFN Exposed Pad | 32-VFQFN Exposed Pad | 32-VFQFN Exposed Pad |
| Supplier Device Package | 32-QFN (5x5) | 32-QFN (5x5) | 32-QFN (5x5) |
