Please send RFQ , we will respond immediately.
| Part Number | UPA2726UT1A-E2-AY | UPA2746UT1A-E2-AY | UPA2724UT1A-E2-AY | UPA2726UT1A-E1-AY |
|---|---|---|---|---|
| Manufacturer | Renesas Electronics America Inc | Renesas Electronics America Inc | Renesas Electronics America Inc | Renesas Electronics America Inc |
| Product Status | Active | Active | Active | Obsolete |
| FET Type | - | - | - | N-Channel |
| Technology | - | - | - | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | - | - | - | 30 V |
| Current - Continuous Drain (Id) @ 25°C | - | - | - | 20A (Ta) |
| Drive Voltage (Max Rds On, Min Rds On) | - | - | - | - |
| Rds On (Max) @ Id, Vgs | - | - | - | 7mOhm @ 10A, 10V |
| Vgs(th) (Max) @ Id | - | - | - | 2.5V @ 1mA |
| Gate Charge (Qg) (Max) @ Vgs | - | - | - | 15 nC @ 5 V |
| Vgs (Max) | - | - | - | - |
| Input Capacitance (Ciss) (Max) @ Vds | - | - | - | 1720 pF @ 15 V |
| FET Feature | - | - | - | - |
| Power Dissipation (Max) | - | - | - | - |
| Operating Temperature | - | - | - | - |
| Mounting Type | - | - | - | Surface Mount |
| Supplier Device Package | - | - | - | 8-DFN3333 (3.3x3.3) |
| Package / Case | - | - | - | 8-VDFN Exposed Pad |
