| Part Number | R7S921047VCBG#AC0 | R7S921048VCBG#AC0 | R7S921057VCBG#AC0 | R7S921047VCBG#BC0 | R7S921040VCBG#AC0 | R7S921041VCBG#AC0 | R7S921042VCBG#AC0 | R7S921043VCBG#AC0 | R7S921045VCBG#AC0 | R7S921046VCBG#AC0 |
|---|---|---|---|---|---|---|---|---|---|---|
| Manufacturer | Renesas Electronics America Inc | Renesas Electronics America Inc | Renesas Electronics America Inc | Renesas Electronics America Inc | Renesas Electronics America Inc | Renesas Electronics America Inc | Renesas Electronics America Inc | Renesas Electronics America Inc | Renesas Electronics America Inc | Renesas Electronics America Inc |
| Product Status | Discontinued at Digi-Key | Discontinued at Digi-Key | Discontinued at Digi-Key | Active | Active | Active | Active | Active | Discontinued at Digi-Key | Discontinued at Digi-Key |
| Core Processor | ARM® Cortex®-A9 | ARM® Cortex®-A9 | ARM® Cortex®-A9 | ARM® Cortex®-A9 | ARM® Cortex®-A9 | ARM® Cortex®-A9 | ARM® Cortex®-A9 | ARM® Cortex®-A9 | ARM® Cortex®-A9 | ARM® Cortex®-A9 |
| Number of Cores/Bus Width | 1 Core, 32-Bit | 1 Core, 32-Bit | 1 Core, 32-Bit | 1 Core, 32-Bit | 1 Core | 1 Core | 1 Core | 1 Core | 1 Core, 32-Bit | 1 Core, 32-Bit |
| Speed | 528MHz | 528MHz | 528MHz | 528MHz | 528MHz | 528MHz | 528MHz | 528MHz | 528MHz | 528MHz |
| Co-Processors/DSP | Multimedia; NEON™ MPE | Multimedia; NEON™ MPE | Multimedia; NEON™ MPE | Multimedia; NEON™ MPE | Multimedia; NEON™ MPE | Multimedia; NEON™ MPE | Multimedia; NEON™ MPE | Multimedia; NEON™ MPE | Multimedia; NEON™ MPE | Multimedia; NEON™ MPE |
| RAM Controllers | - | - | - | - | - | - | - | - | - | - |
| Graphics Acceleration | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Display & Interface Controllers | LCD, LVDS, MIPICSI2, Video | LCD, LVDS, MIPICSI2, Video | LCD, LVDS, MIPICSI2, Video | LCD, LVDS, MIPICSI2, Video | LCD, LVDS, MIPICSI2, Video | LCD, LVDS, MIPICSI2, Video | LCD, LVDS, MIPICSI2, Video | LCD, LVDS, MIPICSI2, Video | LCD, LVDS, MIPICSI2, Video | LCD, LVDS, MIPICSI2, Video |
| Ethernet | - | - | - | - | - | - | - | - | - | - |
| SATA | - | - | - | - | - | - | - | - | - | - |
| USB | USB 2.0 (1) | USB 2.0 (1) | USB 2.0 (1) | USB 2.0 (1) | USB 2.0 (1) | USB 2.0 (1) | USB 2.0 (1) | USB 2.0 (1) | USB 2.0 (1) | USB 2.0 (1) |
| Voltage - I/O | - | - | - | - | - | - | - | - | - | - |
| Operating Temperature | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) |
| Security Features | AES, 3DES, GHASH, RSA, SHA1, SHA224, SHA256 | AES, 3DES, GHASH, RSA, SHA1, SHA224, SHA256 | AES, 3DES, GHASH, RSA, SHA1, SHA224, SHA256 | AES, 3DES, GHASH, RSA, SHA1, SHA224, SHA256 | AES, 3DES, GHASH, RSA, SHA1, SHA224, SHA256 | AES, 3DES, GHASH, RSA, SHA1, SHA224, SHA256 | AES, 3DES, GHASH, RSA, SHA1, SHA224, SHA256 | AES, 3DES, GHASH, RSA, SHA1, SHA224, SHA256 | AES, 3DES, GHASH, RSA, SHA1, SHA224, SHA256 | AES, 3DES, GHASH, RSA, SHA1, SHA224, SHA256 |
| Package / Case | 272-FBGA | 324-FBGA | 272-FBGA | 272-FBGA | 176-LFBGA | 256-LFBGA | 272-FBGA | 324-FBGA | 176-LFBGA | 256-LFBGA |
| Supplier Device Package | 272-FBGA (17x17) | 324-FBGA (19x19) | 272-FBGA (17x17) | 272-FBGA (17x17) | 176-LFBGA (13x13) | 256-LFBGA (11x11) | 272-FBGA (17x17) | 324-FBGA (19x19) | 176-LFBGA (13x13) | 256-LFBGA (11x11) |
