| Part Number | R7FS3A77C3A01CFM#AA1 | R7FS3A77C3A01CFP#AA1 | R7FS3A77C3A01CFM#BA1 | R7FS3A77C3A01CFB#AA1 |
|---|---|---|---|---|
| Manufacturer | Renesas Electronics America Inc | Renesas Electronics America Inc | Renesas Electronics America Inc | Renesas Electronics America Inc |
| Product Status | Active | Active | Active | Active |
| Core Processor | ARM® Cortex®-M4 | ARM® Cortex®-M4 | ARM® Cortex®-M4 | ARM® Cortex®-M4 |
| Core Size | 32-Bit Single-Core | 32-Bit Single-Core | 32-Bit Single-Core | 32-Bit Single-Core |
| Speed | 48MHz | 48MHz | 48MHz | 48MHz |
| Connectivity | CANbus, I²C, IrDA, MMC/SD, SCI, SPI, UART/USART, USB | CANbus, EBI/EMI, I²C, IrDA, MMC/SD, QSPI, SCI, SPI, UART/USART, USB | CANbus, I²C, IrDA, MMC/SD, SCI, SPI, UART/USART, USB | CANbus, EBI/EMI, I²C, IrDA, MMC/SD, QSPI, SCI, SPI, UART/USART, USB |
| Peripherals | DMA, LVD, POR, PWM, WDT | DMA, LCD, LVD, POR, PWM, WDT | DMA, LVD, POR, PWM, WDT | DMA, LCD, LVD, POR, PWM, WDT |
| Number of I/O | 50 | 82 | 50 | 124 |
| Program Memory Size | 1MB (1M x 8) | 1MB (1M x 8) | 1MB (1M x 8) | 1MB (1M x 8) |
| Program Memory Type | Flash | Flash | Flash | Flash |
| EEPROM Size | 16K x 8 | 16K x 8 | 16K x 8 | 16K x 8 |
| RAM Size | 192K x 8 | 192K x 8 | 192K x 8 | 192K x 8 |
| Voltage - Supply (Vcc/Vdd) | 1.6V ~ 5.5V | 1.6V ~ 5.5V | 1.6V ~ 5.5V | 1.6V ~ 5.5V |
| Data Converters | A/D 18x14b; D/A 2x12b | A/D 25x14b SAR; D/A 2x12b | A/D 18x14b SAR; D/A 2x12b | A/D 28x14b SAR; D/A 2x12b |
| Oscillator Type | Internal | Internal | Internal | Internal |
| Operating Temperature | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 64-LQFP | 100-LQFP | 64-LQFP | 144-LQFP |
| Supplier Device Package | 64-LFQFP (10x10) | 100-LFQFP (14x14) | 64-LFQFP (10x10) | 144-LFQFP (20x20) |
